The [System] view gives access to system settings, system information, media information and maintenance tasks.
This section gives an overview of the [Media] section in the [System] view.
The print system uses a central media catalogue from which you can select media for jobs. Correctly defined media settings are important to ensure a high print quality.
When enabled in the Settings Editor, you can add, delete and change media in the media catalogue via the control panel.
Media management on the control panel|
Task |
How |
|---|---|
|
Search media |
Use filters (1) to search for media with a specific size, type, weight or name. |
|
Arrange media |
Click a media setting (2) to change the order according to the setting. |
|
Task |
How |
|---|---|
|
Edit media |
You can change the name, size, type or media family of the media. (3) |
|
Delete media |
You can remove media which you do not need. (4) |
|
Add media to catalogue |
You can add temporary media to the media catalogue (5). (Add temporary media to the media catalogue) |
|
Copy media |
Use the copy function (6) to create new media, based on existing media. |
