Thin white or dark lines along the length of the printed output, at positions that correspond with the printhead boundaries, are usually caused by horizontal misalignment of the printheads.
|
Step |
Action |
|---|---|
|
1 |
Align printheads - Automatic. In the wizard, select the media type that you want to use for printing. |
|
2 |
Check whether the problem is resolved by reprinting the file that showed the problem. If yes, go to step 6. If the problem persists, go to the next step. |
|
3 |
Identify the printhead transitions that need manual printhead alignment (horizontal). |
|
4 |
|
|
5 |
Check whether the problem is resolved by reprinting the file that showed the problem. If the problem persists, repeat the steps 3 and 4 (up to 3 times). |
|
6 |
The best possible result is achieved. |
